Swing Gates
Swing Gates are a classic and reliable solution for securing residential, commercial, and industrial properties. Designed to open inwards or outwards like a door, these gates offer smooth operation, robust security, and elegant aesthetics.
Features
➣ Automatic swing gates can work even under the most difficult conditions
➣ Gates are specially designed with top and bottom pivot mechanism
➣ Dust proof operating mechanism increases the life of our gates
➣ Our Gates leafs are free from sagging/bending
➣ All swing gates are simple and reliable to operate
➣ The driving arm, with its anti shearing shape, allows the leaves to move in total safety.
➣ New mechanical solutions guarantee long life and high quality of its product
➣ Easy to install operator
➣ Hand release with personalized key for emergency manual operation
Technical Specification
| Technical Specification | Description | |
|---|---|---|
| Product | Automatic Swing Gates | |
| Gate Dimension | ||
| Width Min./Max. | Single Leaf : 1000/3500mm Double Leaf :2000/7000mm | |
| Height Min./Max. | 1000/2100mm Larger Dimension on request | |
| Max. Number of Leaves | Single Leaf:1 Nos Double Leaf:2 Nos | |
| Gate Structure | ||
| Outer Frame | Heavy Duty tubular box section (or Customized design available on request) | |
| Internal members | Heavy Duty tubular box section (or Customized design available on request) | |
| Hinges | High precision top & bottom pivoted hinges with ball bearing / heavy duty hinges | |
| Patterns/Designs | ||
| Available gate material | Mild Steel Stainless Steel Hot dip Galvanized Steel Cast Iron | |
| Sheets | M.S/GI/Perforated /Aluminium sheets Polycarbonate / Acrylic / PVC Sheet/Glass/Wood | |
