Fire Rated Rolling Shutters

Fire Rated Rolling Shutters serve as one of the critical means of fire safety for commercial, industrial, and residential buildings. Fire rated shutters are designed to stop fire from spreading while preventing smoke and flames, thus protecting property and preserving lives. When there is a fire emergency, the Fire Rated Shutter automatically close or can be operated manually, creating a solid barrier in protecting people and property while enabling safe evacuation.Fire Rated Rolling Shutters are manufactured from steel, and tested with extreme heat, will withstand extreme temperatures for the period 60, 120, or depending on specifications, 240 minutes. Fire Rated Rolling Shutters are typically used in factories, warehouses, basements, shopping malls, parking garages, hotels, and commercial complexes where fire safety is a priority.

Unlike traditional shutters, Fire Safety Rolling Shutters have heat sensors and fire alarm systems that automatically close during a fire. This eliminates human error, and allows for fast compartmentalization to inhibit the spread of fire to other areas in a building.

In addition to their fire rated aspects, these shutters are easy to operate, maintain and repair. Compact design saves space and being available in a variety of designs offer many personal touches to help it become part of the building design

The most important aspect of Industrial Fire Shutters is that not only do they protect valuable goods, but help buy time for people to safely evacuate the building. These benefits should be taken into consideration when looking at modern fire safety regulation.

Fire Rated Rolling Shutter

Features

Fire Rated Rolling Shutters acts as a barrier & prevents the fire spread in case of fire breakout from one area to other.
➣ The door comes down gradually in case of fire automatically after receiving signal from fusible link
➣ The shutter has been tested to BS476 Part 22. Providing up to 120 minutes of protection .
➣ All steel components of the fire rolling shutters are designed and fixed to provide complete sealing.
➣ Newly designed & tested G type guide specially for fire rolling shutters
➣ All components of our shutters are made from High Grade Steel.
➣ All the Fire Rated Rolling Shutters are available in a number of different finishes or can be powder coated in customized colors.
➣ Electric release and delay timer can be provided as optional accessories to meet specific customer requirements

Technical Specification

Technical SpecificationDescription
ProductMotorized Fire rated rolling shutters
Door Dimension
Width Min. /Max.1000/7000mm
Height Min. /Max.1000/7000mm
Max. Area 49.0Sqm
Larger Dimension on request
Opening DirectionVertical
Mounting LocationInside/Outside
Mounting SurfaceSide Brackets : On Concrete /steel
Side Guides : on Concrete /Steel/ Masonry
Fire rating duration2 hour / 4 hour
Comply ToBS 476 Part 22
Certificate The shutter has been tested to BS476 Part 22. Providing up to 240 minutes of protection .

Slat DetailsGI Single Skin 1.00 mm to 1.2 mm thick flat fire retardant profile
